Angelus keeps with its tradition of utilizing technologically forward materials to manufacture highly complicated and aesthetically interesting timepieces. The House stretches the limit of its famous diving tourbillon movement, adding a 5-day power reserve to its list of features.

While meeting the required diver’s watch criteria, the U51 Diver Tourbillon comes with high technical features. In fact, the A-310 calibre is dedicated to efficiency, with a silicon lever escapement and with all bridges as plates made of titanium. Furthermore, Angelus’ engineers and watchmakers pushed the boundaries with a remarkable 5-day power reserve while keeping the 28,800 vibrations per hour (4 Hz) frequency, ensuring a high precision. Finally, the tourbillon cage is set on a ball bearing instead of pivots to gain in stability.

Even though the U51 Diver Tourbillon is intended as a high-performance sporty timepiece, the skeletonised movement has been carefully decorated with sandblasted finishing, enhancing the natural colour variations of the titanium.

The 45 mm titanium case features two large screw-down crowns. The two-position crown at 4 o’clock is used for winding and setting the time, while the crown at 2 o’clock is used to rotate the unidirectional 60-minute rotating bezel. Opposite, at the 9 o’clock position, a helium escape valve is placed to ensure the watch’s water resistance to 300 meters (1,000 feet), even during saturation diving so the helium molecules could not make their way into the case under pressure.

Careful attention has been given to the aesthetic of the U51 Diver Tourbillon. The case is masterfully manufactured with a subtle interplay between sandblasted, brushed and polished surfaces, which takes full advantage of the titanium’s unique colours properties. The bezel of the case as the chapter ring are carved, recalling waves. The open display appeals with a contrasting chapter ring of stormy blue and striking orange colours. The hands, indexes and Arabic numerals are all filled with Super-Luminova for optimal readability.

The U51 Diver Tourbillon comes on a matching blue rubber strap embossed with an Angelus logo and a titanium folding buckle.

U51 Diver Tourbillon – Technical specifications

Functions – Hours, minutes, small seconds, unidirectional rotatable 60-minute indicator

Movement-
Calibre > A-310, mechanical hand-wound, one-minute flying tourbillon
Jewels > 23
Diameter > 32.80 mm
Height > 4.30 mm
Power reserve > 120 hours (5 days)
Frequency > 4 Hz / 28,800 vph
Lever escapement > Silicon
Decoration > Sandblasted plates and bridges, wheels with Angelus six-spoke design, tourbillon cage with chamfered and polished edges

Dial – Openwork with blue and orange chapter ring. Hours’ indexes, chapter ring’s Arabic numbers and hands filled with Super-Luminova

Case –
Material > Grade 5 titanium, sandblasted, brushed or polished finishing
Diameter > 45.00 mm
Thickness > 12.47 mm
Crowns > Screwed and engraved with Angelus logo
Crystal > Box shaped sapphire with anti-reflection coating both sides
Back > Sapphire
Water resistance > 300 m / 1,000 ft

Strap
Material > Blue rubber embossed with Angelus logo
Buckle > Folding, grade 5 titanium

Limited edition – 25 pieces

Reference 0TDCT.E01A.K008D

World retail price CHF 32’800 without taxes (prices can be subject to change)

www.angelus-watches.com

After entering the scene as a diver’s watch like no other, the Angelus U50 Diver Tourbillon returns in a bold black limited edition.

The U50 Diver Tourbillon Black Edition stands out with its uniquely structured manufacture skeleton movement and dark tones. While conceived with all the properties sought in a diver’s watch, the U50 Diver Tourbillon is high-performance timepiece. With its stealthy black silhouette, this limited edition blends into any situation.

Crafted in a 46mm-wide lightweight yet robust titanium case with a black DLC treatment all over, the U50 Diver Tourbillon features two large screw-down crowns. The two-position crown at 4 o’clock is used for winding and setting the time, while the crown at 2 o’clock is used to rotate the unidirectional 60-minute rotating bezel.

Opposite, at the 9 o’clock position, a helium escape valve is there to ensure the watch’s water resistance of 300 meters (1,000 feet), even during saturation diving so the helium molecules could not make their way into the case under pressure.

Instead of a solid dial, the U50 Diver Tourbillon features an open face with a dark but legible hours’ ring in grey, as well as white Super-Luminova on the indexes. Matching the dial, the hours, minutes and seconds’ hands are black plated and filled with Super-Luminova. Both face and case back crystals are made of antireflective sapphire.

The result of years of intensive R&D by Angelus’ engineers and watchmakers, the U50 Diver Tourbillon’s A-300 mechanical hand-wound caliber is designed as a skeleton from the ground up rather than simply being a cut-out version of an existing movement.

Much reduced in weight, it has maximum rigidity from its beam-type bridges and the fact that all the movement’s main elements, such as the wheels and barrel, are firmly secured between two plates. This design replaces the conventional main plate and bridges construction and massively increases the mechanical resistance of the movement.

Furthermore, the watch’s rigidity is enhanced by the Angelus in-house six-spoke design, which reinforces the wheel train and protects the skeletonized ratchet and barrel. Finally, the movement is entirely manufactured in-house.

With its core functions – hours, minutes, small seconds – the A-300 caliber has a 55-hour power reserve. The 4 Hz / 28,800 vph frequency is a guarantee for precision. Even though the caliber is intended as a high-performance, it has painstakingly executed with snailed black DLC coating and chamfered edges, matching the blacked-out allure of the U50 Diver Tourbillon Black Edition.

The U50 Diver Tourbillon Black Edition comes on a black rubber strap bearing the Angelus logo, with a Bback DLC titanium pin buckle, completing the look of this 25-piece limited edition diver’s watch.

U50 Diver Tourbillon Black Edition – Technical Specifications

Functions Hours, minutes, small seconds and unidirectional rotatable 60-minute indicator
Movement Calibre A-300, mechanical hand-wound, one-minute flying tourbillon
Jewels 23
Diameter 32.80 mm
Height 4.30 mm
Power reserve 55 hours
Frequency 4 Hz / 28,800 vph
Decoration Black DLC coated, snailed and chamfered plates and bridges, wheels with Angelus six-spoke design, mirror-polished tourbillon cage with chamfered and polished edges, balance wheel black treated
Dial Openwork with grey chapter ring. Indexes, Arabic numbers and hands filled with Super-Luminova
Case Material Grade 5 titanium, black DLC coated
Diameter 46.00 mm
Thickness 12.47 mm
Crowns Screwed and engraved with Angelus logo
Crystal Box shaped sapphire with anti-reflection coating both sides
Back Sapphire
Water resistance 300 m / 1,000 ft
Strap Material Black rubber embossed with Angelus logo
Buckle Pin, grade 5 titanium, black DLC coated
Limited edition 25 pieces
Reference number 0TDNT.D01A.K008T
World retail price CHF 30’750 without taxes (prices can be subject to change)

www.angelus-watches.com
